Lab Autoclave

Lab Autoclave(SN210)

Item Code：241054

Model：SN210

Power Source：AC200～240V

Origin：Japan

Product Summary

High-performance, easy operation and ergonomically designed sterilizer featuringeasy top loading and handling of samples

Features

Maximum sterilizing temperature goes up to 135°Csuitable for protein modification

By simple setting and operation, these sterilizersmanage ordinary sterilization, sterilizationof culture mediums and liquids, and melting ofculture mediums

Custom programs can be saved for repeateduse

Standard equipped with timer start and pre-heatingfeatures for the efficient use of time and coolingfan to shorten cool down timetime

Mobile on wheels

Lid interlock mechanism, Drain bottle unset alarm, Memory malfunction, Automatic shutdown when malfunctioning,Self-diagnostic functions

Specifications

Item Code

241054

Model

SN210

System

Automatic high-pressure steam sterilization

Operating temperature range

45～135℃　45～80℃（Preheating temperature）/45～60℃（Heat-retention process）/65～100℃（Solution process）/105～135℃（Sterilization）

Max. working pressure

0.255MPa

Ambient temperature

5～35℃

Lid

Manual upward opening with an interlock for safety

Heater

100V, 600W×2 units

Exhaust valve

One exhaust valve and one slow release valve

Connection ports for optional accessories

Total 3 ports. Female thread for sample temp. sensor (1/4" ), Female thread for chamber temp. sensor (1/4" ), Female thread pressure sensor (Branching from the solenoid valve tubing)

Cooling fan

Axial fan motor

Temp. controller

PID control by microprocessor

Temp. display / setting

Digital display / digital setting by ▲/▼ keys

Timer / Timer resolution

0 or 1 min. to 99 hrs 59 min. / 1 min.

Operation mode

Instrument sterilization course, Liquid sterilization course, Sterilization and keep warm course, Melting and keep warm course, Customer-programmed course

Other function

Key locking, Presetting, Saving, Preheating, Forced cooling, Sample temperature sensor (option), Pattern locking, Up to 20 error log saving, Display of accumulated working time / Present time, ON-OFF beeping setting

Safety device

Sensor failure detection, SSR short-circuit, Broken heater wire, Prevention of idle heating (Liquid expansion type), Alarm against the absence of a drain bottle, Failure in locking the lid, Memory error detection, Pressure relief valve (0.255 MPa)

Accessories

2 pcs. stainless steel mesh basket (Dia.209×D204mm), OSM-60/Vapor cup×1, Drain bottle×1, Drain board×1, Filter×1

Internal dimensions（φ×H mm）

φ240×445mm

External dimensions（W×D×H mm）

400×530×840mm

Internal capacity

20L

Power Source

AC200～240V

Weight

65kg
